Laser Cutting
Laser Cutting, for the Perfect Cut
What is Laser Cutting?
Laser cutting is a high-precision manufacturing process that utilizes a focused laser beam to cut through various materials with exceptional accuracy and speed. It is widely used in industries such as manufacturing, aerospace, automotive, electronics, and construction for cutting, engraving, and marking a wide range of materials.
Laser Source: Laser cutting machines are equipped with a high-powered laser source, typically CO2 which is what we use at Graepels.
Graepels offer a comprehensive suite of services, including profiled components, laser-cut text, and decorative metal art, all backed by our commitment to excellence and a wealth of technical capabilities.
For all your laser cutting needs.
Graepels offer a range of laser cutting options
- Laser cutting General – unique specified work as per customer drawings
- Profiled Components
- Decorative Laser Cutting
- Considerations
- Technical Capabilities
- Services
- Applications & Industries Served
- Benefits of Laser Cutting
Material Type: Different machines can laser cut different materials, Graepels offer stainless steel, mild steel, and aluminum, depending on your application we recommend using material and grades suitable for their intended use.
Openings: Laser cutting can produce finer cuts and more intricate detailing compared to other metal manufacturing although laser cut edges can be smooth it still might not be appropriate for the application. Evaluate your safety, aesthetics, and functional considerations requirements.
Material Thickness: Laser cutting can cut a wide range of metal thicknesses, but the process may be optimised for certain thickness ranges. Consider the required thickness of the metal for the application, as well as the laser cutting system’s capabilities and limitations. Thicker materials may require higher laser power and longer processing times.
Surface Finish: Laser cutting can produce smooth, clean edges on metal parts without the need for additional finishing processes. However, the quality of the surface finish may vary depending on factors such as material type, thickness, laser power, and cutting speed. Consider the desired surface finish for the application and select the appropriate laser cutting parameters to achieve it.
Cost: Laser cutting can be cost-effective for producing high-precision metal parts in small to medium quantities. However, the cost of laser-cut metal parts may vary depending on factors such as material type, thickness, complexity of the cut, and production volume. Consider the overall cost of laser-cut metal parts, including material costs, processing costs, and any additional finishing or post-processing requirements, and compare it to alternative manufacturing methods. Our reps may point you in the direction of perforated metal or woven mesh depending on your requirements.
- Material Specifications: Stainless Steel, Mild Steel and Aluminum
- Material Thickness: Enquiry specific – As a general rule we can comfortably cut up to half the maximum material thickness range which would be 12mm mild steel, 8mm Stainless Steel and 4mm Aluminium
- Sheet Size: Up to 3000 x 1500mm
- Size and Shape openings: There are no limits to shapes and sizes of openings. The only limit is your imagination!
CAD Design: Graepels can work with your drawings to ensure accuracy and precision manufacturing to customers specifications.
- High Precision: Laser cutting provides exceptional accuracy and precision, allowing for intricate and complex designs to be cut with tight tolerances.
- Customisation: Laser cutting enables prototyping and customisation of parts, allowing for iterations and design changes. This flexibility is particularly valuable for industries such as aerospace, automotive, and consumer electronics, where product development cycles are short, and customisation is common.
- Minimal Material Waste: The narrow width of the laser beam minimizes material waste
