Welded Mesh
Welded Mesh, Strength in every wire
What is Welded Mesh?
Welded mesh, also known as welded wire mesh, is a type of prefabricated grid or sheet made by welding together longitudinal and transverse wires at their intersections. This process creates a strong and durable mesh structure with uniform openings, making it suitable for various applications in construction, industrial, agricultural, and residential settings.
Welded mesh is stocked in sheet and coil in mild steel, galvanised and stainless steel. A selection of standard meshes are held Ex Stock. Non-standard are available to order.
Download pdf
- Considerations
- Technical Capabilities
- Services
- Applications & Industries Served
- Benefits of Woven Wire Mesh
Please Note: Graepels offer expert advice on all considerations listed to ensure optimal results and the highest quality output for your application.
Woven wire mesh is available in a variety of materials, configurations, and weave patterns, allowing for versatility in design and application. It can be customized to meet specific requirements for filtration, screening, separation, reinforcement, protection, and more.
- Metal Types & Grades: High Tensile Steel, Stainless Steel, Galvanised Steel, Mild Steel, Corten and other materials by special request
- Wire Diameter: Choose the appropriate wire gauge (thickness) based on the desired strength and durability of the welded mesh. Thicker wires offer greater strength but may increase weight and cost, while thinner wires may be more economical but could sacrifice strength.
- Weld Mesh Aperture: The mesh size should be selected based on the specific application requirements, such as security, ventilation, or filtration.
- Pitch: Pitch includes wire diameter and aperture
- % Open Area: The mesh size of the aperture and the number of openings per linear meter
- Sheet Size: Galvanised mesh is available in rolls. Stainless steel mesh is also available in rolls. Consider handling and weight.
- Finishes: Options include galvanized coating for corrosion resistance, PVC coating for added durability and color options, or powder coating for decorative finishes.
- Fabrication: General fabrication is offered for all our products for customers who do not fabricate themselves. Speak with the Graepels team for information regarding framing and other capabilities including folding and welding.
- Wire Aperture (opening): 6mm –150mm (mild steel and stainless-steel) please speak to a rep for more information on possibilities.
- Metal Types & Grades: Galvanised and stainless steel, other materials available on request
- Pitch and Pattern: A variety of pitches and patterns are available from our standard, decorative and bespoke range.
- Wire Diameter: 0.6mm up to 10mm thick
- Sheet Sizes: 900mm in width and 30m in coil length. Galvanised mesh is available in rolls from 0.5mm thick to 3mm thick from 6mm mesh to 50mm mesh from 900mm wide upwards. Stainless steel mesh is also available in rolls. Please contact us for further details. Standard meshes in heavier wire are available in sheets mostly 2500×1250 but other sizes are available on request.
- % Open Area: All Open Area possible however, the standard open area is between 50%-70%
- Ventilation and Light Transmission: Depending on the mesh size and configuration, welded mesh can provide ventilation and allow for the transmission of natural light while still maintaining security and privacy. This is particularly beneficial in applications such as building facades, partitions, and enclosures.
- Environmental Benefits: Welded mesh made from recyclable materials such as steel can contribute to sustainability efforts by reducing the consumption of raw materials and minimizing waste generation. Additionally, the longevity of welded mesh reduces the need for frequent replacements, further reducing environmental impact.
- Versatility: Welded mesh finds applications in a wide range of industries, including construction, agriculture, manufacturing, and transportation. It can be used for fencing, reinforcement, security barriers, animal enclosures, shelving, and more, highlighting its versatility.
